| Application |
|
These products are suitable for the connection of copper conductors(section1.5-1000mm2)in power cable with electronic equiment. They are made of with higher 99.9 percent pure copper tube T2 and coated with tin.Working temperature-55℃-150℃. |
|
| Type |
φ |
D |
d |
L |
| SC(JGK)-1.5 |
φ4.2,φ5.2 |
3.5 |
1.8 |
18 |
| SC(JGK)-1.5 |
φ4.2,φ5.2,φ6.2 |
4 |
2.5 |
19 |
| SC(JGK)-4 |
φ5.2,φ6.2 |
4.8 |
3.1 |
21 |
| SC(JGK)-6 |
φ5.2,φ6.2,φ8.2 |
5.5 |
3.8 |
24 |
| SC(JGK)-10 |
φ6.2,φ8.2 |
6.8 |
4.8 |
25.5 |
| SC(JGK)-16 |
φ6.2,φ8.2,φ10.5 |
7.5 |
5.5 |
30.5 |
| SC(JGK)-25 |
φ6.2,φ8.2,φ10.5 |
9 |
7 |
34 |
| SC(JGK)-35 |
φ6.2,φ8.2,φ10.5,φ12.5 |
10.5 |
8.2 |
38 |
| SC(JGK)-50 |
φ8.2,φ10.5,φ12.5 |
12.5 |
9.8 |
45 |
| SC(JGK)-70 |
φ8.2,φ10.5,φ12.5 |
14.5 |
11.5 |
50 |
| SC(JGK)-95 |
φ10.5,φ12.5 |
17.5 |
13.8 |
55.5 |
| SC(JGK)-120 |
φ12.5,φ16.5 |
19.5 |
15.5 |
63 |
| SC(JGK)-150 |
φ12.5,φ16.5 |
21 |
16.5 |
71 |
| SC(JGK)-185 |
φ16.5 |
23.5 |
18.8 |
78 |
| SC(JGK)-240 |
φ16.5 |
26.5 |
21 |
92 |
| SC(JGK)-300 |
φ16.5,φ20.5 |
30 |
24 |
102 |
| SC(JGK)-400 |
φ16.5,φ20.5 |
34 |
26.5 |
113 |
| SC(JGK)-500 |
φ16.5,φ20.5 |
38 |
30 |
123 |
| SC(JGK)-630 |
φ20.5 |
45 |
35 |
135 |
| SC(JGK)-800 |
φ20.5 |
50 |
39 |
170 |
| SC(JGK)-1000 |
φ20.5 |
56 |
44 |
200 | |
|
| Type |
φ |
D |
d |
L |
| SC(JGA)-1.5 |
φ4.2,φ5.2 |
3.5 |
1.8 |
18 |
| SC(JGA)-2.5 |
φ4.2,φ5.2,φ6.2 |
4 |
2.5 |
19 |
| SC(JGA)-4 |
φ5.2,φ6.2 |
4.8 |
3.1 |
21 |
| SC(JGA)-6 |
φ5.2,φ6.2,φ8.2 |
5.5 |
3.8 |
24 |
| SC(JGA)-10 |
φ6.2,φ8.2 |
6.8 |
4.8 |
25.5 |
| SC(JGA)-16 |
φ6.2,φ8.2,φ10.5 |
7.5 |
5.5 |
30.5 |
| SC(JGA)-25 |
φ6.2,φ8.2,φ10.5 |
9 |
7 |
34 |
| SC(JGA)-35 |
φ6.2,φ8.2,φ10.5,φ12.5 |
10.5 |
8.2 |
38 |
| SC(JGA)-50 |
φ8.2,φ10.5,φ12.5 |
12.5 |
9.8 |
45 |
| SC(JGA)-70 |
φ8.2,φ10.5,φ12.5 |
14.5 |
11.5 |
50 |
| SC(JGA)-95 |
φ10.5,φ12.5 |
17.5 |
13.8 |
55.5 |
| SC(JGA)-120 |
φ12.5,φ16.5 |
19.5 |
15.5 |
63 |
| SC(JGA)-150 |
φ12.5,φ16.5 |
20.5 |
16.5 |
71 |
| SC(JGA)-185 |
φ16.5 |
23.5 |
18.8 |
78 |
| SC(JGA)-240 |
φ16.5 |
26.5 |
21 |
92 |
| SC(JGA)-300 |
φ16.5,φ20.5 |
30 |
24 |
102 |
| SC(JGA)-400 |
φ16.5,φ20.5 |
34 |
26.5 |
113 |
| SC(JGA)-500 |
φ16.5,φ20.5 |
38 |
30 |
123 |
| SC(JGA)-630 |
φ20.5 |
45 |
35 |
135 |
| SC(JGA)-800 |
φ22.5 |
50 |
39 |
170 |
| SC(JGA)-1000 |
φ22.5 |
56 |
44 |
200 | | |
