■UT30B
3 1/2 digits LCD with a Max.reading of 1999
Data-hold function
Low battery indication
Diode & hFE test
Overload protection
|
| Function |
Measuring Range |
Accuracy |
| DCV |
200m-2000m-20-200-500V |
±0.8% |
| ACV |
200-500V |
±1.2% |
| DCA |
200μ-2000μ-20m-200mA-10A |
±1.0% |
| OHM |
200-2000-20K-200K-20MΩ |
±1.0% |
| Diode check |
2.8V/1mA |
|
| hFE |
Vce 3V,Ib 10μA |
|
| Size/weight |
130x74x38mm / 163g |
|
| Battery |
6F22(9V)x1 |
|
| Accessories |
Instruction Manual,Test Lead |
| | |
|
|
|
■DT830A
■3 1/2 digits LCD with a Max. reading of 1999
■Low battery indication
■Battery check function
■Overload protection
Accessories:
Test lead, battery [6F22(9V)x1], instruction manual
|
| Function |
Measuring Range |
Accuracy |
| DCV |
200m-2000m-20-200-1000V |
±0.8% |
| ACV |
200-750V |
±1.5% |
| DCA |
2000μ-20m-200mA |
±1.2% |
| OHM |
200-2000-20K-200K-2000KΩ |
±1.0% |
| Diode check |
2.8V/1mA |
|
| Battery check |
1.5V, 9V |
|
| Size / weight |
126x70x28mm/137g |
| | |
|
|
|
■DT830D
■3 1/2 digits LCD with a Max. reading of 1999
■Data-hold function
■Low battery indication
■Overload protection
■Audible continuity
Accessories:
Test lead, battery [6F22(9V)x1], instruction manual
|
| Function |
Measuring Range |
Accuracy |
| DCV |
200m-2000m-20-200-1000V |
±0.8% |
| ACV |
200-750V |
±1.5% |
| DCA |
2000μ-20m-200m-10A |
±1.2% |
| OHM |
200-2K-20K-200K-2000KΩ |
±1.0% |
| Diode check |
3V/0.8mA |
|
| hFE test |
Vce 3V, Ib 10μA |
|
| Signal output |
50Hz Square |
|
| Size / weight |
126x70x28mm / 137g |
| | |
|
|
|
■M300
■3 1/2 digits LCD with a Max. reading of 1999
■Low battery indication
■Overload protection
■Audible continuity
Accessories:
Test lead, battery [23A(12V)×1], instruction manual |
| Function |
Measuring Range |
Accuracy |
| DCV |
2-20-200-500V |
±0.8% |
| ACV |
200-500V |
±1.5% |
| DCA |
200mA |
±1.2% |
| OHM |
2K-20K-200K-2000KΩ |
±1.2% |
| Diode check |
3.2V/1mA |
|
| Size / weight |
120x70x28mm / 110g |
| | |
|
|
|
■DT920B
■3 1/2 digits LCD with a Max. reading of 1999
■Pocket digital multimeter
■Overload protection
Accessories:
Test lead, battery [23A(12V)x1], instruction manual
|
| Function |
Measuring Range |
Accuracy |
| DCV |
2-20-200-450V |
±1.0% |
| ACV |
200-450V |
±1.8% |
| DCA |
200mA |
±1.0% |
| OHM |
2K-20K-200K-2000KΩ |
±1.2% |
| Diode check |
3V/0.8mA |
|
| Size / weight |
112x62x23mm / 96g |
| | |
