■EC8813
■3 1/2 digits LCD with a Max. reading of 1999
■Measurement from 0.1PF to 20mF
■LCD display with unit annunciator
■Overload protection
Accessories:
Test lead, battery [23A(12V)x1], instruction manual
|
| Function |
Measuring Range |
Accuracy |
| CAP |
200p-2000p-20n-200n-2μ-20μ-200μ-2000μ-20mF |
±1.5% |
| Size/weight |
400-40MΩ |
| | |
|
|
|
■3211D
■3 1/2 digits LCD with a Max.reading of 1999
■Easily operated with one hand
■Built-in TTL and CMOS logic tester
■Data-hold function
■Auto ranging
■Auto polarity indication
■Diode test
■Audible continuity
■Overload protection
|
| Function |
Measuring Range |
Accuracy |
| DCV |
200m-2-20-200-500V |
±0.8% |
| ACV |
2-20-200-500V |
±1.2% |
| DCA |
200mA |
±1.2% |
| ACA |
200mA |
±2.5% |
| OHM |
200-2K-20K-200K-2M-20MΩ |
±1.0% |
| Logic tester |
L<1.5V,H>3.5V |
|
| Size / weight |
185x31x22mm/80g |
|
| Battery |
SR44(1.5V)x2 |
|
| Accessories |
Instruction Manual,Test Lead |
| | |
|
|
|
■266
■3 1/2 digits LCD with a Max. reading of 1999
■Data-hold function
■Low battery indication
■Audible continuity
■Plug-in insulation tester adapter 500VDC(optional)
Accessories:
Test lead, battery [6F22(9V)x1], instruction manual
carrying case
|
| Function |
Measuring Range |
Accuracy |
| DCV |
1000V |
±0.8% |
| ACV |
750V |
±1.2% |
| ACA |
200-1000A |
±2.5% |
| OHM |
200-20KΩ |
±1.0% |
|
20M-2000MΩ(with 2621) |
±4.0% |
| Size / weight |
230x70x37mm / 310g |
| | |
|
|
|
■MT486A
■3 1/2 digits LCD with a Max. reading of 1999
■Low battery indication
■Data-hold function
■Overload protection
Accessories:
Test lead, battery [6F22(9V)x1], instruction manual
carrying case |
| Function |
Measuring Range |
Accuracy |
| DCV |
600V |
±0.8% |
| ACV |
450V |
±1.0% |
| ACA |
2-20-200A |
±2.0% |
| Diode check |
3.2V/1.2mA |
|
| Size / weight |
175×43×29mm/200g |
| | |
|
|
|
■MG26A
■Pocket size and light weight
■Versatility of use with ACV & ACA measurement
■Overload protection
Accessories:
Test lead, instruction manual carrying case
|
| Function |
Measuring Range |
Accuracy |
| ACV |
300-600V |
±1.0% |
| ACA |
3-15-60A |
±2.0% |
| Clamp size |
φ15mm(max.) |
|
| Size / weight |
120×70×35mm/170g |
| | |
