| Specification |
Manufacture standard: IEC60947-2
Fixing type thermal trip
Fixing type magnetic trip |
|
| Max. rated short-circuit breaking capacity |
|
| Hull |
220/240Vac |
380/415Vac |
660/690Vac |
250Vdc* |
| H126H |
65kA |
25kA |
- |
10kA |
| H226H |
35kA |
25kA |
- |
- |
| H226N |
40kA |
40kA |
12kA |
10kA |
| H226E |
100kA |
70kA |
14kA |
20kA | |
|
| Description |
Rated current(A) |
Description |
Rated current(A) |
| H126H-25kA |
|
H226N-40kA |
|
| MCCB |
16 |
MCCB |
63 |
| MCCB |
20 |
MCCB |
80 |
| MCCB |
25 |
MCCB |
100 |
| MCCB |
32 |
MCCB |
125 |
| MCCB |
40 |
MCCB |
160 |
| MCCB |
50 |
MCCB |
200 |
| MCCB |
63 |
MCCB |
225 |
| MCCB |
80 |
|
|
| MCCB |
100 |
|
|
| H226H-25kA |
|
H226E-70kA |
|
| MCCB |
63 |
MCCB |
63 |
| MCCB |
80 |
MCCB |
80 |
| MCCB |
100 |
MCCB |
100 |
| MCCB |
125 |
MCCB |
125 |
| MCCB |
160 |
MCCB |
160 |
| MCCB |
200 |
MCCB |
200 |
| MCCB |
225 |
MCCB |
225 | |
|
| Accessory and auxiliary equipment |
Revolve the hand handle the organization locks
-AA auxiliary switch, 2NO+2NC
-UV owe-voltage trip, 415V~
-SR cent trip, 240V~
-UV2 owe-voltage trip, 240V~ |
|
| Dimension |
