Size(mm):59x45x25
On-off time: Below 0.5 period of 1ms+ load current
Load Voltage:25V-250VAC,H:150V-450VAC
Output Voltage Drop:1.8Vmax.
Off Leakage Current:
Type zero-crossing:10mA max.(at 220VAC) 15mA max.(at 380VAC)
Type random: 5mA max.(at 220VAC) 10mA max.(at 380VAC)
Insulation Resistance:100MΩ min. (at 500VDC)
Dielectric Strength:2000VAC 50Hz /1min
Operating Temperture:-20℃~80℃

Size(mm):59x45x25
On-off time:Below 0.5 period of 1ms+ load current
Load Voltage:25V-250VAC,H:150V-450VAC
Output Voltage Drop:1.8Vmax.
Off Leakage Current:
Type zero-crossing:10mA max.(at 220VAC) 15mA max.(at 380VAC)
Insulation Resistance:100MΩmin. (at 500VDC)
Type random:5mA max.(at 220VAC) 10mA max.(at 380VAC)
Insulation Resistance:100MΩmin. (at 500VDC)
Dielectric Strength:2000VAC 50Hz /1min
Operating Temperture:-20℃~80℃

Size(mm):62.5x45x23.5
Control method:
Control Voltage:3-32VDC 80-250VAC
Load Voltage: 24V-380VAC,H:90V-480VAC
Output Voltage Drop:1.5Vmax.
Off Leakage Current:
Insulation Resistance:1000MΩ 500VDC Voltage testing
Dielectric Strength:4000Vrms Input terminal-utput terminal
2500Vrms Input terminal, output terminal-adiator
Operating Temperture:-20℃~80℃

Size(mm):62.5x45x23.5
Control method:
Control Voltage:3-32VDC 80-250VAC
Load Voltage: 24V-380VAC,H:90V-480VAC
Output Voltage Drop:1.5Vmax.
Off Leakage Current:
Insulation Resistance:1000MΩ 500VDC Voltage testing
Dielectric Strength:4000Vrms Input terminal-utput terminal
2500Vrms Input terminal, output terminal-adiator
Operating Temperture:-20℃~80℃

Size(mm):62.5x45x23.5
Control method:VA:Solid voltage regulator
Control Voltage:Outside-controlled adjustsble potentiometer470KΩ-560KΩ/2W
Load Voltage:24V-380VAC,H:90V-480VAC
Output Voltage Drop:1.5Vmax.
Off Leakage Current:
Insulation Resistance:1000MΩ 500VDC Voltage testing
Insulation Resistance:1000MΩ 500VDC Voltage testing
Dielectric Strength:4000Vrms Input terminal-utput terminal
2500Vrms Input terminal, output -terminaladiator
Operating Temperture:-20℃~80℃

Size(mm):57.4x44.8x28
Control method:DC control of AC, AC control of AC, Solid voltage regulator
Load Voltage: 24V-380VAC,H:90V-480VAC
Output Voltage Drop:1.5Vmax.
Off Leakage Current):5mA No build-in RC absorption ring
Insulation Resistance: 1000MΩ 500VDC
Dielectric Strength:4000Vrms Input terminal-utput terminal 2500Vrms Input terminal, output terminal-adiator
Operating Temperture:-20℃~80℃
