| usage |
a.The daily maximum is ten groups of on/off and the weekly maximum is seventy groups of on/off. The arbitrarily setting of daily on-off program or of ten groups of on-off program is available. The minimum on-off intervals is 1min. Hand operation is available.
b.The plug-in mode avoids wiring, featuring small volume, wide working temperature and strong anti-interference, etc.
c.It can serve in neon lamp, road lamp and water & material feeding in aquiculture, tool, switchgear cubicle and distribution case for automatical control. At family, it can serve as turning on and off lamp, TV and air conditioner by timing. Then the family will enter intelligence era. |
>●Rated voltage: 220V/50Hz
●Mains voltage range: 160V~240V
●Resistance load: 16A
●Power consumption: <2VA
●Timing range: 1min~168h
●Ten groups of timing is available in the form of hand and automation
●Timing error: <±0.5s/day
●Ambient temperature range: -25℃~60℃
●Relative humidity: <95% |
|
| Time setting |
>Press the key of “CLOCK” and then press the key of “WEEK” to determine the week.
Press the key of “HOURS” to determine the hours and press the key of “MIN” to determine the minute. Releasing the key of “MIN” means that the timing will start. In a need to adjust the setting, it is necessary to press unloosely or press repeatedly relevant key. |
|
| Timing program setting |
| >Seven mode of automatica on/off timing. select following program combination is of recommendation. |
●From Monday to Sunday
●Every day of a week
●From Monday to Friday
●From Saturday to Sunday
●From Monday to Saturday
●Monday, Tuesday, Wednesday
●Thursday, Friday, Saturday |
After selection of the above-mentioned mode, then it is to set day, hour, minute todetermine on/off time.
Press the key of"PROG"to set the time for first on and the left of the screen will display "MN1" which means that the entry of first group of on program will be available.
Press the key of "WEEK"to select needful mode among the program package, and press the keys of "HOURS"and "MIN"to select the needful.
Repress the key of "PROGpand the crystal screen will display "OFF1" which means that entry of first group of on program is available. Respectively press the key of "WEEK" "HOURS"and "MIN"to set. Repress the key of "PROG" to enter another group of program set. And repeating such procedure can set residual nine groups of on/off modes. To such idel mode, the user can cancel it with the key of "RST/RCL" which will leave the "--:--" on the screen. |
After setting of on/off program, press the key of "CLOCK" and the crystal screen will return to present time. Then the timing function will start.
Repeatedly press the key of "PROG"to watch the program that has been set in turn. |
|
| Hand function |
>Press the key of "ON/AUTO/OFF"to select the three modes of PERMANENT ON--UTOMATION--ERMANENT OFF. In case of the mode of AUTOMATION, the timer can automatically operate in accordance with set program.
The set program just runs in case of the mode of AUTOMATION. In case of the mode of "PERMANENT OFF" the timer will automatically turn off. In case of the mode of "PERMANENT ON" the timer will automatically run. |
|
| Reset |
| Press the key of "RESET"with pen to reset. The time and on-off program. |
●Note
●No use at external lead.
●No connect it to the switch of another timer
●No connect it to the electrical appliance which are running
●No exceed maximum load range(see what printd at it抯 surface)
●No connect it to air heater out of monitor or oven with heating wire exposed
●No insert the needle or any metal into power socket-out
●No place it at such places as subject to damp, overhigh or overlow temperature and easy to collision or shake.
●Resort to specialist to detachment for servicing
●Clean enclosure and crystal screen with cloth. No use corrosive liquid and water. |
|
| Remarks |
|
The maximum load of electronical timer is print in the mark on the products. No use out of nominated range. Refer to Note for details as above . |
|
